Hastelloy X SocketWeld Fittings

UNS N10665 Socketweld Fittings, DIN 2.4617 Socketweld Fittings

We are Manufacture, Suplier & Export of Hastelloy X Socket Weld Forged Fittings in the national and international markets by complying with all their standards and also providing the clients with responsive services. Hastelloy X Socket Weld Forged Fittings. The products we offer are unparalleled to others, high in quality, durability, and uniform and precise. The X Socket Weld forged fittings we offer are superior quality corrosion resistance and provide high-quality finish. We meet the international standards for precision of our forged fittings. Our company provides a wide range of Alloy X Socket weld Fittings to our global customers. We focus in manufacturing custom shape and special size socket weld fittings for our clients. Our Hastelloy X Socket weld Fittings are made in compliance with the international quality standards and by making use of the best quality inconel alloy.

The standard heat – treatment of Hastelloy X Forged Socket Weld Tee Fittings is at a temperature of 2150 Degree F (1177 Degree C) followed by rapid cooling. Other heat – treatment temperatures of Hastelloy X Forged Socket Weld Cap Fittings also may be effective for certain forms and conditions.

Specification Of Hastelloy X Socket Weld Fittings

Specifications ASTM B564 / ASME SB564
Size 1/8″ NB to 4″ NB Socket Weld
Dimensions ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Class 3000/ 6000/ 9000lbs
From 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Inserts, Caps, Nipples, Unions, Equal Tees & Reducing Tees.

Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Hastelloy X 2.4617 N10665

Chemical Composition

Grade C Mn Si P S Co Mo Ni Fe Cr
Hastelloy X 0.05 – 0.15 1.00 max 1.00 max 0.04 max 0.03 max 0.50 – 2.50 8.00-10.00 Balance 17.00 – 20.00 20.50-23.00

Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.22 g/cm³ 1355°C 655 MPa 240 MPa 35 %
