Duplex Steel S31803 Socketweld Fittings

UNS S31803 Socketweld Fittings, DIN 1.4462 Socketweld Fittings

We are Manufacture, Suplier & Export of UNS NO S31803 Socket Weld Forged Fittings that are actually manufactured from High Quality of Standard Raw Materials and are designed as per with national and international standards. When it comes to the fabrication of Duplex Steel S31803 Socket Weld Forged Fittings (also referred as WNR 1.4462 Forged Fittings), we have the experience and knowledge to make sure it is engineered, built and inspected to the highest standards. Duplex Steel UNS S31803 Forged Socket Weld Fittings has good weldability and can be welded by several methods.

Designed to combine improved resistance to stress corrosion cracking, pitting and crevice corrosion, these Duplex Steel UNS S31803 Forged Socket Weld Fittings is roughly double the strength of standard austenitic stainless steel. Our Duplex S31803 Socket Weld Cross Fittings provide meaningful results relating to many practical service applications where resiststance SCC in two sodium chloride-containing environments.

Specification Of Duplex Steel S31803 Socket Weld Fittings

Specifications ASTM A182 / ASME SA182
Size 1/8″ NB to 4″ NB Socket Weld
Dimensions ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Class 3000/ 6000/ 9000lbs
From 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Inserts, Caps, Nipples, Unions, Equal Tees & Reducing Tees.

Equivalent Grades

STANDARD WERKSTOFF NR. UNS
Duplex S31803 1.4462 S31803

Chemical Composition

Grade C Mn Si P S Cr Mo Ni N Fe
Duplex S31803 0.030max  2.00 max 1.00 max 0.030max 0.020 max 22.0-23.0  3.0-3.5  4.50-6.50 0.14-0.20  63.72 min

Mechanical Properties

Grades Density (g/cm 3) Density (lb/in 3) Melting Point (°C) Melting Point (°F)
S31803 7.805 0.285 1420 – 1465 2588 – 2669
