Inconel 825 Fasteners

UNS N08825 Fasteners, DIN 1.4858 Fasteners

We are Manufacture, Suplier & Export of Incoloy 825 Fasteners which is a nickel-iron-chromium alloy with additions of molybdenum, copper and titanium elements. This nickel-iron-chromium alloy chemical composition is designed to provide better resistance against many corrosive environments. Incoloy 825 Bolts is kind of similar to Incoloy Alloy 800 but has improved resistance to aqueous corrosion so it will give better resistance against aqueous corrosion environments. These Incoloy 825 Fasteners has tremendous resistance to in cooperation reducing and corroding acids, to stress-corrosion cracking, and also to localize outbreaks such as opposing and crevice oxidization.

Incoloy 825 Nuts has many different industrial applications, some of which include: Propeller shafts, Tank trucks, Phosphoric acid evaporators, Hot vessels for food, water, sea water, etc. Our heavy duty UNS N08825 Incoloy 825 hex bolt is a hardware device that provides mechanical fastening or tightening, either permanently or temporarily. They are also quick to install and remove.

Specification Of Inconel Alloy 825 Fasteners

Standard ASTM B425, ASME SB425
Size M 02 to M 33
Length 3 mm to 200 mm
Threads: METRIC, BSW, BSF, UNC, UNF or as required
Standard: DIN, ISO, JIS, GB, IS, BS, ASTM, ANSI – American National Standards Institute
  • ANSI B 18.2.4 2M
  • ANSI B 28.2.4 1M
  • Stud Bolt length are defined in ASME B16.5 standard
  • Hex nuts are defined in ASME B18.2.2
  • ASME B18.5
  • BS en iso 3506

DIN: DIN 931, DIN 933, DIN 934, DIN 970

UTS – Unified Thread Standard : UNC, UNF, UNEF, UNS, NPT, NPTF

ISO – International Organization for Standardization : ISO 4032, ISO 4033, JIS standards

Scope of Manufacturer
  • Up to M36 / 1-1/2” Dia, up to 1100mm lg
  • CNC Machined Fasteners, up to M100 / 4” Dia, up to 1500mm lg
Dia M6 to M64 (1/4" - 2.5")
Length 12 MM - 500 MM (Upto 20 Inch)
IS 1363, 1364
DIN 931, 933
ISO ISO 3506
Form of: Hex, Square, Round, Threading as per Gauge Etc.
Head Drive: Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Test Certificate: Manufacturer Test Certificate as per EN 10204 / 3.1
Finishing: Zinc (yellow, white, blue, black), black oxide, , Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Passivated, Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Mechanically Applied coating and some special one like DACROMET
Production Process M2-M24: Cold Froging, hot forging M24-M100, , machining and CNC for Customized connecting element
Types Nuts, Bolts, Screws, Socket Screw, Sockets, Studs, Screw, Nut, Spring Washers, Hex Set Screw, Socket Hexagon Head Screw, Cap Screw, Wing Screw, Pan Head Screw, Machine Screw, Socket Head Cap Screw, Allen Cap screw, Wing Screw, Washers, Studs, Anchors, Hex Nut,Marine Anchors, Hexagon Nut, Hex Coupling Nut, Hex Domed Cap Nuts, Square Nut, Stud Bolts, Hex Head Bolts, Anchor Bolt, U- Bolts, J Bolts, T-Head Bolts, Mushroom Head Square Neck Bolts, Eye Bolt, Foundation Bolts, Structural Bolts

Equivalent Grades

Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
Incoloy 825 N08825 NA 16 NiCr21Mo 2.4858 NFE30C20DUM ЭП703 NCF 825

Chemical Composition

Grade C Mn Si Fe S Cr Cu Ti
825 min. 22.0 19.5 1.5 0.6
max. 0.05 1.0 0.5 0.015 23.5 3.0 1.2

Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
825 Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa –220 30
