Super Duplex S32760 Round Bars
UNS S32760 Round Bar, DIN 1.4410 Rods
We are a manufacturer, supplier, and exporter of Super Duplex Steel UNS S32760 Bar (UNS S32760) and Super Duplex Steel S32760 Rods of various sizes, dimensions, and standards at competitive market rates. These Round Bars are available in a variety of sizes ranging from 5 mm to 500 mm, including Super Duplex Steel S32760 Forged Bar, Super Duplex Stainless Steel S32760 Hex Bar, Super Duplex Steel S32760 Bright Bar, Flat Bar, Hexagonal Bar, and Threaded Bar. If you don't see the size you're searching for or if you need another type of round bar, please contact us.
Super Duplex Steel S32760 Round Bars exhibit remarkable corrosion resistance to a wide range of media, including exceptional resistance to crevice corrosion and pitting in seawater and other chloride-containing atmospheres, with Critical Pitting Temperatures exceeding 50 degrees Celsius. Super Duplex S32760 Round Bars are made of steel that has been industrialized for applications requiring high strength and corrosion resistance. Super Duplex Steel S32760 Square Bars combines the most important characteristics of both austenitic and ferritic steel.
Specification Of Super Duplex S32760 Round Bars
| Dimensions | DIN, EN, ASTM, JIS, ASME, BS, AISI |
|---|---|
| Standard | ASTM A276 / A479, ASME SA276 / A479 |
| Hex Bar size | 2-100mm A/F |
| Round bar size | Diameter: 3-~800mm |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Square bar size | 4 to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging etc. |
Equivalent Grades
| STANDARD | UNS | WNR. |
|---|---|---|
| Super Duplex S32760 | S32760 | 1.4410 |
Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
Mechanical Properties
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
