Super Duplex Steel S32750 Threaded Fittings
UNS S32750 Threaded Fittings, DIN 1.4410 Threaded Fittings
We manufacture, supply, and export Super Duplex Steel UNS S32750 Forged Threaded Fittings and Super Duplex Steel UNS S32750 Threaded Pipe Fittings that are designed to meet national and international raw material quality standards, ensuring durability and high quality. The low carbon content of UNS S32750 Super Duplex Forged Threaded Pipe Fittings significantly reduces the danger of carbide precipitation at grain boundaries during heat treatment, making the alloy highly resistant to carbide-related intergranular corrosion. Super Duplex Stainless Steel UNS S32750 Forged Threaded Fittings, which can be cold or hot forged.
Super Duplex Stainless Steel UNS S32750 Forged Threaded Fittings are highly corrosion resistant in a wide range of corrosive substances. Super Duplex Stainless Steel UNS S32750 Forged Threaded Fittings are well renowned for their high impact strength, with no ductile-brittle transition and just a little loss in impact energy as temperature decreases.
Specification Of Super Duplex Steel S32750 Threaded Fittings
| Specifications | ASTM A182 / ASME SA182 |
|---|---|
| Size | 1/8″ NB to 4″ NB Screwed-Threaded |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Class | 2000lb/ 3000lb/ 6000lbs |
| From | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, Unions, Equal Tees & Reducing Tees, Plugs. |
Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex 2507 | 1.4410 | S32750 |
Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
Mechanical Properties
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32750 | 7.8 | 0.281 | 1350 | 2460 |
