Duplex UNS S32205 Pipe Fittings

UNS S32205 Pipe Fittings, DIN 1.4462 Fittings

We are a manufacturer, supplier, and exporter of Duplex S32205 Pipe Fittings (UNS S32205) in a variety of sizes, specifications, and standards at competitive market pricing. Our stock includes Duplex Steel UNS S32205 Elbows, Eccentric & Concentric Reducers, Stub Ends, Long & Short Radius Elbows, and Pipe End Caps in sizes ranging from 1/2″ to 10″. If you do not find the size you are searching for, or if you require other types of pipe fittings, please contact us.

We are pleased to introduce ourselves as one of the leading stockists and suppliers of UNS S32205 Buttweld Long Radius Elbows, Duplex Steel S32205 Butt Weld Pipe Bend, Duplex Steel S32205 Short Radius Elbow, and Duplex Steel S32205 Buttweld Stub End. The supplier supplies these pipe fittings with the appropriate specifications, which include ASTM A815, ASME SA815, and ASTM A182 & ASME SA182 standards. Pipe fittings, flanges, and forged are available in a variety of types, including seamless, fabricated, and welded.

Specification Chart of Duplex Steel S32205 Pipe Fittings

Specifications ASTM A815 / ASME SA815
Pipe Fittings size Seamless Duplex Steel Butt Weld Fittings: 1/2" - 10"
Welded Duplex Steel Butt Weld Fittings: 1/2" - 48"
Pipe Fittings Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Pipe Fittings Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Pipe fittings Types Seamless / ERW / Welded / Fabricated
Manufacturing Standards ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011, DN15-DN1200
BS : BS4504, BS4504, BS1560, BS10
JIS : JIS B2311, JIS B2312, JIS B2313, JIS B2316
GOST : GOST 17375, GOST 17376, GOST 30753, GOST 17378, GOST 17379, GOST 17380
EN: EN10253-1, EN10253-2
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Connection Welding
Pipe Fittings Elbow Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D.
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Pipe Fittings Size Range ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Pipe Fittings Manufacturing process Push, Press, Forge, Cast, etc.
Buttweld Fittings Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Specialized manufacturer of 90º Elbows, Couplings, Reducers, Inserts, Caps, Nipples, 45º Elbows, Tees, Crosses, Equal Tees & Reducing Tees
Pipe Fittings uses & application
  • Fittings To Connect Pipe & Tubes in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc
  • Schedule 10 Duplex Steel S32205/S32205 fittings are an economical alternative for lower-pressure applications.
  • Schedule 40 Steel S32205/S32205 fittings have a thicker wall for higher-pressure applications.
Material Test Certificates (MTC) for Duplex Steel S32205/S32205 Pipe Fittings as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

Equivalent Grades

STANDARD WERKSTOFF NR. UNS
Duplex Steel S32205 1.4462 S32205

Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
Duplex Steel S32205 0.030 max 2.0 max 1.0 max 0.030 max 0.020 max 22.0 – 23.0 3.0 – 3.5 4.50 – 6.50 0.14 – 0.20

Mechanical Properties

Density (g/cm 3) Density (lb/in 3) Melting Point (°C) Melting Point (°F)
7.805 0.285 1420 – 1465 2588 – 2669
